Blustream HEX100ARC-KIT-V2 - Odbiornik i nadajnik HDBaseT do 100m, RS-232, dwukierunkowa podczerwień, dwukierunkowe zasilanie PoH, optyczne wejście audio, ARC, 3
portowy przełącznik LAN - HDBaseT™ Extender Set - 100m (4K up to 70m), Bi-directional IR & RS-232, Bi-directional PoH (PoE), HDMI loop-out, Audio Breakout, ARC, 3 x LAN switch and supports HDCP 2.2



Zapraszamy do współpracy w zakresie projektowania, sprzedaży i montażu profesjonalnych systemów:

  • audiowizualnych
  • Digital Signage
  • wideokonferencyjnych i telekonferencyjnych
  • sterowania (integracyjnych).



  • Odbiornik i nadajnik HDBaseT do 100m, RS-232, dwukierunkowa podczerwień, dwukierunkowe zasilanie PoH, optyczne wejście audio, ARC, 3 portowy przełącznik LAN

  • Our Platinum Range of HDBaseT products offer the very best in performance and flexibility. The HEX100ARC-KIT-V2 extender set is an industry leading 4K HDBaseT solution delivering HDMI with HDCP 2.2 support, Bi-directional IR, RS232 and PoH (PoE) up to lengths of 100m over a single CAT cable. The HEX100ARC-KIT-V2 also provides enhanced features including HDMI loop-out on the Transmitter, ARC via HDMI or Optical (S/PDIF) and an integrated 3-port Ethernet switch.
  • Advanced HDBaseT™ technology offering uncompressed video and audio with zero latency
  • Extends HDMI up to a distance of 100m over single CAT cable at 1080p
  • Supports 4K UHD video up to 70m (3840 x 2160 @30Hz 4:4:4, 4096 x 2160 @24Hz 4:4:4, and 4K @60Hz 4:2:0)
  • Supports all industry standard video resolutions including VGA-WUXGA and 480i-4K
  • Supports 3D signal display
  • Supports CEC bypass (Consumer Electronics Control)
  • Features 1x HDMI loop out for integrating local displays or cascading to further signal distribution devices
  • Supports ARC (Audio Return Channel) from display via HDMI or Optical digital inputs (to 90m max distance*)
  • Supports audio return to HDMI, Optical digital and analogue L/R audio outputs (DAC PCM only)
  • Supports all known HDMI audio formats including Dolby TrueHD, Dolby Atmos, Dolby Digital Plus and DTS-HD Master Audio transmission
  • Integrated 3-port 10/100BaseT Ethernet switch (LAN Serving)
  • Bi-directional RS-232 pass through
  • Bi-directional IR from all input and output locations
  • Supplied with Blustream IR receiver and emitter
  • Bi-directional PoH (Power over HDBaseT) to power extenders from either transmitter or receiver end
  • HDCP 2.2 support

* Where ARC is required over longer distances, it is highly recommended that shielded CAT cable be used





Specyfikacja:

HEX100ARC-TX-V2

  • Video Input Connectors: 1x HDMI Type A, female
  • Video Output Connectors: 1x HDBaseT RJ45 connector, 1x HDMI Type A, female
  • Audio Output Connectors: 2x RCA (L/R), 1x Optical (SPDIF)
  • Ethernet port: 1x RJ45 connector
  • RS-232 serial port: 1x DB-9 female
  • IR Input ports: 1x 3.5mm stereo jack
  • IR Output ports: 1x 3.5mm mono jack
  • 2x mounting bracket

HEX100ARC-RX

  • Video Input Connectors: 1x HDBaseT RJ45 connector,
  • Video Output Connectors: 1x HDMI Type A, female
  • Audio Input Connectors: 1x Optical (SPDIF)
  • Ethernet port: 3x RJ-45 connector
  • RS-232 serial port: 1x DB-9 female
  • IR Input ports: 1x 3.5mm stereo jack
  • IR Output ports: 1x 3.5mm mono jack



  • Mounting kit included
  • Ind. Unit Dimensions (W x D x H): 114mm x 135mm x 24mm (RX),    143mm x 135mm x 25mm (TX), without connections
  • Ind. Unit Dimensions (W x D x H): 114mm x 139mm x 24mm (RX),    143mm x 140mm x 25mm (TX), with connections
  • Box Dimensions (W x D x H): 340mm x 285mm x 60mm
  • Shipping Weight (Kit): 0.9kg
  • Operating Temperature: 32°F to 104°F (0°C to 40°C)
  • Storage Temperature: -4°F to 140°F (-20°C to 60°C)
  • Power Supply: 1x 15V/2A DC, screw type connector



Box Contents

1 x HEX100ARC-V2-TX
1 x HEX100ARC-RX
1 x 15V/2A DC power supply
1 x IRR receiver
1 x IR emitter
2 x Mounting brackets
1 x User manual
