SoundTube SM400 i - salony w Katowicach i Toruniu zapraszają - profesjonalne systemy audiowizualne

  • Dodaj recenzję:
  • Producent: SOUNDTUBE
  • Dostępność: Skontaktuj się z nami - magazyn dystrybucyjny

**** Autoryzowany dealer produktów SOUNDTUBE ****

4″ COAXIAL SURFACE-MOUNT SPEAKER

BroadBeam® waveguide technology delivers a consistent dispersion pattern up to 10 kHz for maximum coverage area per speaker. One 4 inch polypropylene woofer and one 1.0 inch convex titanium tweeter with FerroFluid cooling. Includes port plugs and weatherized components for indoor and outdoor applications. Patented ZeroReflection™ enclosure technology for optimal sound reproduction and cabinet rigidity. Easy access, five-position selectable tap switch for 25-, 70.7- and 100-volt applications with transformer bypass position. Iridite-plated aluminum grille with protective powder-coated finish for lasting durability. Includes a tool-free Stealth™ U-bracket mounting system for fast and secure installation. Vertical and horizontal mounting offer precision aiming for indoor and outdoor applications. UL 1480 (UEAY) and CE approved. Included accessories: corrosion and theft resistant U-bracket mount with safety cable, Euroblock connector, paint mask, terminal weather boot, and port plugs. Optional port plugs are included for added weather resistance.

Zapraszamy do współpracy w zakresie projektowania, sprzedaży i montażu profesjonalnych systemów:

audiowizualnych

Digital Signage

wideokonferencyjnych i telekonferencyjnych

sterowania (integracyjnych).



Produkt w magazynie dystrybucyjnym

Zadzwoń do nas w celu ustalenia ceny specjalnej oraz dostępności

tel. 56 657 57 65

tel. 500 227 464



Nominal Impedance

 4 ohm
Impedance (min) 3.7 ohm
Sensitivity dB @ 2.83V/1M 85.5dB
Sensitivity dB @ 1W/1M (2) 82.5dB
Frequency Response (± 3 dB) 97 Hz - 22 kHz
Frequency Response (±10 dB) 76 Hz - 22 kHz
Max. Program Power 35W
Max. Continuous Power RMS 20W
Max. Power SPL @ 1 M 95.5dB
Directivity Factor (Q) (Averaged 100Hz - 10kHz, @ 2kHz) 3.7 (Average 100 Hz - 10 kHz) 3.9 (2 kHz)
Directivity Index (DI) dB (Averaged 100Hz - 10kHz, @ 2kHz) 4.9dB (Average 100 Hz - 10 kHz) 5.9dB (2 kHz)
Tap Selector Weather-proof, five-position tap switch with transformer bypass position
70.7 Volt Transformer Taps 20w / 95.5dB
100 Volt Transformer Taps (dB) 20w / 95.5dB
25 Volt Transformer Taps (dB) 2.5w / 86.5dB
Transformer Options 25 / 70.7 / 100 Volt option with a 4 Ohm direct
Transducer - Low Frequency Driver 4" Polypropylene Cone with Butyl Rubber Surround
Transducer - High Frequency Driver 1" Convex Titanium Tweeter w/ Waveguide
Network Type: Low Pass 12dB per octave, 2nd order
Network Type: High Pass 12dB per octave, 2nd order
Coverage Angle (-6 dB @ 2 kHz) 125 horizontal
163 vertical
Colors Black or white
Inputs 4 Pin, 5.08 mm Euroblock for individual or daisy chain connection
Height (SM = Height) 177 mm / 6.97 in
Diameter (SM = Width) 245.9 mm / 9.68 in
SM Depth (Including Bracket) 189.7 mm / 7.47 in
Weight 2.4 kg / 5.3 lb
Shipping Weight 3.3 kg / 7.3 lb
Packaging 1 per box
Regulatory - UL Approved UL1480A
Regulatory - CE Approved
Regulatory - RoHS approved
Regulatory - IP not planned



Urządzenie objęte gwarancją, realizowaną w systemie door-to-door przez autoryzowany centralny serwis
